1. Setup & Preparation

Machine Inspection – Check rollers, fasteners, cutting blades, and electrical connections. Ensure all components are aligned and free of damage.

Power & Safety Check – Connect the machine to the correct power supply. Verify that emergency stop functions and safety guards are operational.

Material Loading – Place the steel coil (galvanized/stainless steel) onto the decoiler. Adjust feeding guides to ensure smooth and centered material entry.

2. Operation Process

Material Feeding – Gradually feed the steel strip into the machine while keeping it properly aligned to prevent deformities.

Parameter Setup – Use the control panel to set the guide rail’s length, width, and bending specifications. Double-check the settings before starting.

Roll Forming Process – Press Start, and the rollers will gradually shape the material into guide rails. Monitor alignment and adjust if needed.

Cutting Mechanism – The hydraulic or mechanical cutter will automatically cut the rails to the programmed length. Ensure precise cuts with clean edges.

3. Post-Operation & Maintenance

Quality Inspection – Examine the guide rails for dimensional accuracy, smooth edges, and uniformity.

Proper Shutdown – Stop the machine, disconnect power, and clean the working area to remove debris.

Routine Maintenance – Lubricate moving parts, check rollers and blades for wear, and inspect electrical systems regularly for consistent performance.

By following these steps, you ensure smooth production, high-quality output, and the longevity of your Shutter Door Guide Rail Roll Forming Machine.
