1. Machine Setup

Inspect the Machine – Before starting, check the rollers, cutter, electrical components, and fastening systems to ensure everything is in place and properly aligned.

Power & Safety Check – Connect the machine to the appropriate power source. Test the emergency stop function and confirm all safety features are active.

Material Preparation – Load the steel coil (galvanized, PPGI, or aluminum) onto the decoiler. Adjust the guiding system for smooth material flow.

2. Step-by-Step Operation

Feeding the Material – Guide the metal sheet into the entry rollers, ensuring proper alignment to avoid misformation.

Setting the Parameters – On the control panel, input the panel’s width, thickness, and length. Confirm the settings before starting.

Initiating Roll Forming – Press Start, allowing the machine to gradually shape the metal into self-locking panels. Monitor for smooth operation.

Cutting Process – The hydraulic cutting system trims the panels to the programmed length with precision. Ensure all cuts are clean and consistent.

3. Post-Production: Finishing & Maintenance

Quality Check – Inspect the completed panels for accuracy in size, shape, and locking mechanism.

Shutting Down – Turn off the machine, disconnect power, and clear any metal shavings or debris from the rollers and work area.

Regular Maintenance – Lubricate the rollers, check for worn-out cutting blades, and inspect the electrical connections to ensure the machine operates efficiently over time.

By following these steps, you ensure reliable performance, high-quality output, and an extended lifespan for your Self-Lock Wall Panel Roll Forming Machine.
